Eaton MMX34AA9D0 Series User Manual

Parameters
04/10 MN04020001Z-EN
124
Second parameter set (P14)
The selected parameters for a second motor are combined in
parameter group P14. This enables the alternative operation of
two motors at the output of the frequency inverter, even with
different rating specifications.
In the factory setting, the parameters of this second parameter set
(P14) are identical to the factory settings of the basic parameters
(first parameter set) and described in the relevant sections:
• P14.1 - P14.6 = P7.1 - P7.6 (Motor)
• P14.7 - P14.10 = P6.3 - P6.6 (Drives control)
• P14.11 = P11.1, P14.12 = P11.7 (V/f control)
• P14.13 - P14.16 = P8.6 - P8.9 (protection function).
PNU ID Access right
RUN
Value Description Factory setting
(P1.3)
P14.1 1347 - Motor (2PS), rated operational current 4.8
1)
Setting range: 0.2 x I
e
-2xI
e
I
e
= Rated operational current of the frequency inverter
(a Motor rating plate).
P14.2 1352 - Current limit (2PS) 7.2
1)
Setting range: 0.2 x I
e
-2xI
e
1.5 x I
e
P14.3 1350 - Motor (2PS) nominal speed 1440
1720
Setting range: 300 - 20000 rpm
(a Motor nameplate).
P14.4 1351 - Motor (2PS), motor power factor (cos v). 0.85
1)
Setting range: 0.30 - 1.00
(a Motor nameplate).
P14.5 1348 - Motor (2PS), rated operating voltage 230
1)
Setting range: 180 - 500 V (a Motor nameplate).
Pay attention to the supply voltage and the type of circuit in the
stator winding!
P14.6 1349 - Motor (2PS), nominal frequency 50.00
60.00
Setting range: 30 - 320 Hz (a Motor nameplate).
P14.7
1343 - Minimum frequency (2PS) 0.00
0.00 - P14.8 Hz
P14.8 1344 - Maximum frequency (2PS) 50.00
60.00
P14.7 - 320 Hz
P14.9
1345 / Acceleration time (2PS) (acc3) 3.0
0.1 - 3000 s
P14.10 1346 / Deceleration time (2PS) (dec3) 3.0
0.1 - 3000 s
P14.11 1355 - U/f characteristic curve [2PS] 0
(a section “P11.1”, page 111)
0 Linear
1 Quadratic
2 Parameterizable
