Electrical Installation
37
Electrical Installation
i
Warning!
Carry out wiring work only after the frequency inverter
has been correctly mounted and secured.
j
Danger!
Electric shock hazard - risk of injuries!
Carry out wiring work only if the unit is de-energized.
h
Caution!
Debounced inputs may not be used in the safety
circuit diagram.
Fire hazard!
Only use cables, protective switches, and contactors that
feature the indicated permissible nominal current value.
h
Caution!
Debounced inputs may not be used in the safety
circuit diagram.
Ground contact currents in frequency inverters are greater
than 3.5 mA (AC). According to product standard IEC/EN
61800-5-1, an additional equipment grounding
conductor must be connected, or the cross-section of the
equipment grounding conductor must be at least 10 mm
2
.
j
Danger!
The components in the frequency inverter's power section
remain energized up to five (5) minutes after the supply
voltage has been switched off (intermediate circuit
capacitor discharging time).
Pay attention to hazard warnings!
.
h
Complete the following steps with the specified tools and
without using force.
