M-Max
TM
Series
04/10 MN04020001Z-EN
16
Technical data
Part no. Rated current Overload
current
(150 %)
Assigned motor rating Installation
size
I
e
I
e150
P
(230 V, 50 Hz)
P
(230 V, 60 Hz)
[A] [A] [kW] [A]
1)
[HP] [A]
1)
Power connection voltage: 1 AC 115 V, 50/60 Hz
(94-132V
g0%, 45-66Hz g0%)
MMX11AA1D7… 1.7 2.6 0.25 1.4 1/3
2)
1.5
2)
FS2
MMX11AA2D4…
2.4 3.6 0.37 2 1/2 2.2 FS2
MMX11AA2D8…
2.8 4.2 0.55 2.7 1/2 2.2 FS2
MMX11AA3D7… 3.7 5.6 0.75 3.2 3/4 3.2 FS2
MMX11AA4D8… 4.8 7.2 1.1 4.6 1 4.2 FS3
1) Rated motor currents for normal four-pole internally and surface-cooled three-phase asynchronous motors (1500 rpm at 50 Hz, 1800rpm
at 60 Hz).
2) Calculated motor output (no standard value).
The mains voltage of 115 V is raised to 230 V (output voltage) through an internal voltage double connection.
Part no. Rated current Overload
current
(150 %)
Assigned motor rating Installation
size
I
e
I
e150
P
(230 V, 50 Hz)
P
(230 V, 60 Hz)
[A] [A] [kW] [A]
1)
[HP] [A]
1)
Power connection voltage: 1 AC 230 V, 50/60 Hz
(177 - 264 V
g0 %, 45 - 66 Hz g0 %)
MMX12AA1D7… 1.7 2.6 0.25 1.4 1/3
2)
1.5
2)
FS1
MMX12AA2D4…
2.4 3.6 0.37 2 1/2 2.2 FS1
MMX12AA2D8… 2.8 4.2 0.55 2.7 1/2 2.2 FS1
MMX12AA3D7…
3.7 5.6 0.75 3.2 3/4 3.2 FS2
MMX12AA4D8… 4.8 7.2 1.1 4.6 1 4.2 FS2
MMX12AA7D0… 7 10.5 1.5 6.3 2 6.8 FS2
MMX12AA9D6… 9.6 14.4 2.2 8.7 3 9.6 FS3
Power connection voltage: 3AC 230 V, 50/60 Hz
(177 - 264 V
g0 %, 45 - 66 Hz g0 %)
MMX32AA1D7… 1.7 2.6 0.25 1.4 1/3
2)
1.5
2)
FS1
MMX32AA2D4… 2.4 3.6 0.37 2 1/2 2.2 FS1
MMX32AA2D8… 2.8 4.2 0.55 2.7 1/2 2.2 FS1
MMX32AA3D7… 3.7 5.6 0.75 3.2 3/4 3.2 FS2
MMX32AA4D8… 4.8 7.2 1.1 4.6 1 4.2 FS2
MMX32AA7D0… 7 10.5 1.5 6.3 2 6.8 FS2
MMX32AA011… 11 14.4 2.2 8.7 3 9.6 FS3
1) Rated motor currents for normal four-pole internally and surface-cooled three-phase asynchronous motors (1500 rpm at 50 Hz, 1800 rpm
at 60 Hz).
2) Calculated motor output (no standard value).
