Rating data on the nameplate
17
Part no. Rated current Overload
current
(150 %)
Assigned motor rating Installation
size
I
e
I
150
P
(400 V, 50 Hz)
P
(460 V, 60 Hz)
[A] [A] [kW] [A]
1)
[HP] [A]
1)
Power connection voltage: 3AC 400 V, 50/60 Hz
(323 - 528 V
g0 %, 45 - 66 Hz g0 %)
MMX34AA1D3… 1.3 2 0.37 1.1 1/2 1.1 FS1
MMX34AA1D9… 1.9 2.9 0.55 1.5 3/4 1.6 FS1
MMX34AA2D4… 2.4 3.6 0.75 1.9 1 2.1 FS1
MMX34AA3D3… 3.3 5 1.1 2.6 1-1/2 3 FS2
MMX34AA4D3… 4.3 6.5 1.5 3.6 2 3.4 FS2
MMX34AA5D6… 5.6 8.4 2.2 5 3 4.8 FS2
MMX34AA7D6… 7.6 11.4 3 6.6 4
2)
6.4
2)
FS3
MMX34AA9D0…
9 13.5 4 8.5 5 7.6 FS3
MMX34AA012… 12 18 5.5 11.3 7-1/2 11 FS3
MMX34AA014… 14 21 7.5
2)
(15.2)
3)
10
4)
14 FS3
1) Rated motor currents for normal four-pole internally-cooled and surface-cooled three-phase asynchronous motors (1500 min
-1
at 50 Hz, 1800 min
-1
at 60 Hz)
2) Calculated motor output (no standard value).
3) Operation with reduced load torque (about -10 % M
N
)
4) Allocated motor output at a maximum ambient temperature of +40 °C and a maximum pulse frequency of 4 kHz.
