04/10 MN04020001Z-EN
1
About This Manual 5
Notes on the second MMX upgrade 5
Writing conventions 6
Abbreviations and Symbols 7
– Mains supply voltages 7
–Units 7
1 M-Max
TM
Series 9
System overview 9
Checking the Delivery 10
Rating data on the nameplate 11
– Key to part numbers 12
– General rated operational data 14
– Technical data 16
Description of the M-Max
TM 18
Features 18
Selection criteria 20
Proper use 21
Maintenance and inspection 22
Storage 22
Charging DC link capacitors 22
Service and warranty 22
2 Engineering 23
Introduction 23
Electrical power network 24
– Mains connection and configuration 24
– Mains voltage and frequency 24
– Voltage balance 24
– Idle power compensation devices 25
– Mains reactors 25
Safety and switching 26
– Fuses and cable cross-sections 26
– Cables and fuses 26
– Residual-current device (RCD) 26
– Mains contactor 27
EMC measures 27
Motor and Application 28
– Motor selection 28
– Connecting motors in parallel 28
– Motor and circuit type 29
– Bypass operation 30
– Connecting EX motors 30
3 Installation 31
Introduction 31
Installation instructions 31
– Mounting position 31
– Cooling measures 31
– Fixing 32
EMC installation 35
– EMC measures in the control panel 35
– Earthing 35
Contents
