Parameter menu (PAR)
105
PNU ID Access right
RUN
Value Description Factory setting
(P1.3)
P10.1 124 / Fixed frequency FF0 5.00
6.00
0.00 Hz up to the maximum frequency value (P6.4).
This value is only active if for the setpoint input has been set the
parameter P6.2 = 0.
P10.2
105 / Fixed frequency FF1 10.00
12.00
0.00 Hz up to the maximum frequency value (P6.4).
In the factory setting, this value can be called directly via DI3
(control signal terminal 10).
P10.3
106 / Fixed frequency FF2 15.00
18.00
0.00 Hz up to the maximum frequency value (P6.4).
In the factory setting, this value can be called directly via DI4
(control signal terminal 14).
P10.4
126 / Fixed frequency FF3 20.00
24.00
0.00 Hz up to the maximum frequency value (P6.4).
In the factory setting, this value can be called directly by joint
actuation of control signal terminals 10 and 14 (DI3 and DI4).
P10.5
127 / Fixed frequency FF4 25.00
30.00
0.00 Hz up to the maximum frequency value (P6.4).
For activation, parameter P3.11 must be assigned a third digital
input. For example, P3.11 = 5: DI5 (control signal terminal 15).
This value can then be called up directly via DI3.
Note: In the factory setting, DI5 (control signal terminal 15) is
assigned with the error acknowledgement (Reset). Setting
P3.11 = 0 is recommended.
P10.6
128 / Fixed frequency FF5 30.00
36.00
0.00 Hz up to the maximum frequency value (P6.4).
For activation parameter P3.11 must be assigned a third digital
input. For example, P3.11 = 5: DI5 (control signal terminal 15),
see Note on P10.5).
This value can be called directly by joint actuation of control signal
terminals 10 (DI3) and 15 (DI5).
P10.7
129 / Fixed frequency FF6 40.00
48.00
0.00 Hz up to the maximum frequency value (P6.4).
For activation, parameter P3.11 must be assigned a third digital
input. For example, P3.11 = 5: DI5 (control signal terminal 15),
see Note on P10.5).
This value can be called directly by joint actuation of control signal
terminals 14 (DI4) and 15 (DI5).
P10.8
130 / Fixed frequency FF7 50.00
60.00
0.00 Hz up to the maximum frequency value (P6.4).
For activation, parameter P3.11 must be assigned a third digital
input. For example, P3.11 = 5: DI5 (control signal terminal 15),
see Note on P10.5).
This value can be called directly by joint actuation of control signal
terminals 10 (DI3), 14 (DI4) and 15 (DI5).
