04/10 MN04020001Z-EN
Modbus Process Data
143
Status word (ID 2101)
Information on the device status and messages are defined in the
status word:
General status word (ID 2102)
Actual speed (frequency actual value)
The actual speed of the frequency inverter is within a value range
of 0 and 10,000. In the application, this value is scaled to a
percentage in the frequency range between the defined minimum
and maximum frequencies.
Bit Description
Value = 0 Value = 1
0 Drive not ready Ready for operation (READY)
1 Stop Running operation message (RUN)
2
Clockwise rotating field (FWD) Anticlockwise rotating field (REV)
3 No fault Fault detected (FAULT)
4 No warning Warning active (ALARM)
5 Acceleration ramp Frequency actual value equals setpoint value definition
6
- Zero speed
7
Speed control deactivated Speed control activated
8 - 15 Not used
Bit Description
Value = 0 Value = 1
0 - Control level = Fieldbus (BUS)
1 - Setpoint input = Fieldbus (BUS)
2 - 10 Not used
11 Remote input not active Remote input active
The status of a selected digital input (P3.28) is read out.
12
Actuation (P3.37) not active Actuation (P3.37) active
13
- Control level = Control signal terminals (I/O)
14
- Control level = KEYPAD
15
- Control level = Fieldbus (BUS)
1514131211109876543210
MSB LSB
