Appendix
04/10 MN04020001Z-EN
160
Part no.
M-Max
TM
Rated voltage Rated input
current without
mains reactor
Part no. of the allocated
mains contactor
Conventional
thermal current
(DILEM, DILM7)
I
th
= I
e
AC-1 at
+50 °C
(50 Hz) (60 Hz)
U
LN
U
LN
I
LN
I
N
[A] [A]
MMX34AA1D3… 3AC400V 3 AC 480 V 2.2 DILEM-10 20
MMX34AA1D9… 3AC400V 3 AC 480 V 2.8 DILEM-10 20
MMX34AA2D4… 3AC400V 3 AC 480 V 3.2 DILEM-10 20
MMX34AA3D3… 3AC400V 3 AC 480 V 4 DILEM-10 20
MMX34AA4D3… 3AC400V 3 AC 480 V 5.6 DILEM-10 20
MMX34AA5D6… 3AC400V 3 AC 480 V 7.3 DILEM-10 20
MMX34AA7D6… 3AC400V 3 AC 480 V 9.6 DILEM-10 20
MMX34AA9D0… 3AC400V 3 AC 480 V 11.5 DILM7 21
MMX34AA012… 3AC400V 3 AC 480 V 14.9 DILM7 21
MMX34AA014… 3AC400V 3 AC 480 V 18.7 DILM7
2)
21
1) The use of paralleling links (P1DILEM) is suggested when using the DILEM-10 for even flow path loads.
2) DILM1 with
UL
®
installation (a Note).
h
For UL
®
-compliant installation and operation, the mains
side switching devices must allow for a 1.25 times higher
input current. The switching devices meet this
requirement.
