Eaton MMX34AA9D0 Series User Manual

Appendix
04/10 MN04020001Z-EN
172
Table 20: Allocation of the motor reactors with frequency inverters of the 400-V class
(maximum power supply: 750 V ±0%, maximum permitted frequency: 200 Hz)
Part no.
M-Max
TM
Rated
operatio
nal
current
Part no. of the
allocated motor reactor
Rated
operational
current of the
motor reactor
Assigned motor
rating
Assigned motor
rating
Up to 40 °C Up to 50 °C 40 °C 50 °C (400 V, 50 Hz) (460 V, 60 Hz)
I
e
I
2
I
2
P I
M
P I
M
[A] [A] [A] [kW] [A]
1)
[HP] A]
1)
MMX34AA1D3… 1.3 DEX-LM3-005 5 0.37 1.1 1/2 1.1
MMX34AA1D9… 1.9 DEX-LM3-005 5 0.55 1.5 3/4 1.6
MMX34AA2D4…
2.4 DEX-LM3-005 5 0.75 1.9 1 2.1
MMX34AA3D3…
3.3 DEX-LM3-005 5 1.1 2.6 1-1/2 3
MMX34AA4D3… 4.3 DEX-LM3-005 5 1.5 3.6 2 3.4
MMX34AA5D6… 5.6 DEX-LM3-005 DEX-LM3-008 5 8 2.2 5 3 4.8
MMX34AA7D6… 7.6 DEX-LM3-008 8 3 6.6 4
4)
6.2
4)
MMX34AA9D0… 9 DEX-LM3-011 11 4 8.5 5 7.6
MMX34AA012… 12 DEX-LM3-011
2)
DEX-LM3-016 11 16 5.5 11.3 7-1/2 11
MMX34AA014…
14
3)
DEX-LM3-016 16 7.5
3)
15.2
3)
10 14
1) The rated operational currents of the allocated motor outputs apply for normal four-pole, internally and externally ventilated three-phase
asynchronous motors with 1500 rpm (at 50 Hz) and 1800 rpm (at 60 Hz).
2) For rated motor currents greater than 11 A, the DEX-LM3-016 (16 A) must be used here.
3) Reduced rated operational data: Ambient temperature maximum +40 °C, maximum pulse frequency: 4 kHz, side mounting space (left and right)
>10 mm.
4) Guide value (calculated), no standard rating.
