XS series operating manual
XS user manual v0.55 - 27 -
Timer
The measurement voltage can stay permanently ( timer value set to 0 sec.) or during a time
between 1 and 999 sec. adjustable by 1 sec. step.
Rise time is adjustable in time (seconds), from 2s to 60s by step of 1s, or in voltage increase (V/s).
Fall time is adjustable in time (seconds), from 0 to 60s by step of 1s, or in voltage increase (V/s).
In case ramps are set in V/s, the value translated into seconds must stay within the time limits given
above. For example, if the test voltage is 1000VDC and the ramp up set by the user is 1000V/s, this
value will not be accepted because it is equivalent to a ramp up time of 1s < 2s, whereas if the value
of the ramp up is 450V/s, it will be accepted.
