XS series operating manual
XS user manual v0.55 - 47 -
IMPORTANT:
In the REMOTE TRIG. mode, the unit will stop the measurement but will not display any
SAFETY LOOP open message.
If you have selected the REMOTE TRIG. mode and if the connections 1-9 and 2-10 are already done
when selecting a measurement function (Megohm,Hipot, ….), the following message is displayed
INPUT ERROR
and the REMOTE TRIG. mode is automatically removed.
Please refer to the above procedure to select correctly the REMOTE TRIG. mode.
Interface selection
The XS series units can be remote controlled by the following interfaces:
RS232, IEEE 488 (GPIB), ETHERNET et par interface API.
At the same time, only one interface can be selected
If an interface is not installed in the unit, its selection displays an error message: OPTION MISSING.
For more details about those interface capability, please refer to the related section of this manual.
Sequence selection (Option 04)
For DXS models only, if the option 04 is installed, this function allows to to perform automatic
cycling of the megohm and dielectric strength functions.
Display on the LCD screen the various sequence modes with the UP and DOWN arrows :
OFF,M+H,H+M,M+H+M,.....
The M letter shows an insulation resistance measurement and the H letter shows a dielectric
strength test. Operating the sequence mode is recalled in the measurement windows by the
following drawing symbol:
In a M+H sequence the unit performs first an insulation test and then a dielectric test. It is
necessary to set the parameters specially the test times before running a sequence. In case of a
fault during the test, the sequence is stopped. When operating in sequence mode, at power on,
the first sequence function type is automatically selected. When attempting to trigger the
measurement mode in a function type which is not the first one of the sequence, the following
message is displayed:
SEQUENCE ERROR
Escape of the function and select either another function or another sequence mode.
