Eclipse AVN7000 User Manual

150
Adjusting sound quality
How to operate the unit with an optional 5.1 ch decoder/AV matrix unit connected
Adjusts the dialog and music output level heard from center speaker.
Touch or for CENTER
LEVEL.
● The center level can be adjusted within
-10 to 10 (in units of one).
: Increase the level.
: Decrease the level.
● Touch after making
settings. The sound adjustment mode
adjustments will be saved and the
system will return to the previous
operation screen.
Adjusts the dialog and music output level heard from rear speaker.
Touch or for REAR
LEVEL.
● The rear level can be adjusted within
-10 to 10 (in units of one).
: Increase the level.
: Decrease the level.
● Touch after making
settings. The sound adjustment mode
adjustments will be saved and the
system will return to the previous
operation screen.
Setting the CENTER LEVEL
BACK
Setting the REAR LEVEL
BACK

Eclipse AVN7000 Specifications

General

Brand	Eclipse
Model	AVN7000
Category	Car Navigation system
Language	English
