Operation and parameterization 66
Manual econ sens3 Version 3.0
Modbus register addresses
Measurement – current value
Measurement – current value
Measurement – current value
Measurement – current value
32 bit, integer, switched
32 bit, integer, switched
Included in the table are all register addresses that can be read over Modbus. All data are offered in
data type: float with 2 registers and a total of 4 bytes.
The data are located in registers 2 to 110 and 1002 to 1110. The data in the Modbus registers can be
retrieved in the format:
- Big endian (high byte before low byte) - Register 2 to 110
- Little endian (low byte before high byte) - Register 1002 to 1110.
The Modbus functions “Read Holding Registers” (0x03) and “Read Input Registers” (0x04) are
supported. Register 2 to 110 (1002 to 1110) are addressed as 1 to 109 (1001 to 1119).
An example: if the register for the counter status active power of phase L3 is to be read out, register 7
is input for big endian byte order and 1007 for little endian.
Active power (counter status)
Active power (counter status)
Active power (counter status)
Active power (counter status)
Reactive power (counter status)
Reactive power (counter status)
Reactive power (counter status)
Reactive power (counter status)
