F9 Fetal & maternal Monitor Service Manual Principle Introduction
- 33 -
7.2.8 LVDS LCD
LCD applies a 12.1” screen with LCDS interface from Taiwan AU Company. Its main technical
specifications are as follows:
Items Unit Specifications
Screen Diagonal [mm] 310 (12.1”)
Active Area [mm] 246.0(H) x 184.5(V)
Pixel H x V 800(x3) x 600
Pixel Pitch [mm] 0.3075(H) x 0.3075(V)
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode Normally White
Typical White Luminance (ICFL= 6mA) [cd/m
2
] 200 Typ. (center)
Contrast Ratio 500:1 Typ.
Optical Rise Time / Fall Time [msec] 10/25 Typ.
Nominal Input Voltage VDD [Volt] +3.3 Typ.
Typical Power Consumption (VDD line +
VCFL line)
[Watt] 7.8 Typ.
Weight [Grams] 640 + 10
Physical Size [mm] 279.0(W) x 209.0(H) x 11(D)
Electrical Interface LVDS
Support Color Native 262K colors (RGB 6-bit driver)
Temperature Range:
Operating
Storage(Shipping)
[°C]
[°C]
-10 to +65
-30 to +70
