PPENDIX

| Software Specifications

Management Features

– 128 –

MULTICAST FILTERING IGMP Snooping

ADDITIONAL FEATURES DHCP Client

LLDP (Link Layer Discover Protocol)

SNMP (Simple Network Management Protocol)

MANAGEMENT FEATURES

IN-BAND MANAGEMENT Web-based HTTP or SNMP manager

SNMP Management access via MIB database

Trap management to specified hosts

STANDARDS

IEEE 802.1AB Link Layer Discovery Protocol

IEEE 802.1D-2004 Spanning Tree Algorithm and traffic priorities

Spanning Tree Protocol

Rapid Spanning Tree Protocol

IEEE 802.1p Priority tags

IEEE 802.1Q VLAN

IEEE 802.1X Port Authentication

IEEE 802.3-2005

Ethernet, Fast Ethernet, Gigabit Ethernet

Link Aggregation Control Protocol (LACP)

IEEE 802.3ac VLAN tagging

ARP (RFC 826)

DHCP Client (RFC 2131)

ICMP (RFC 792)

IGMP (RFC 1112)

IGMPv2 (RFC 2236)

IGMPv3 (RFC 3376) - partial support

RADIUS+ (RFC 2618)

SNMP (RFC 1157)

SNMPv2c (RFC 2571)
