| SNMP Settings

Specifying SNMP Trap Receivers

– 94 –

2. Specify the IP address of management station that will receive SNMP

trap messages.

3. Specify a configured community string for the trap receiver.

4. Click Apply.

Figure 31: SNMP Trap Receiver Settings
