C
HAPTER
12
| Link Layer Discovery Protocol
LLDP Neighbors
– 89 –
LLDP NEIGHBORS
Use the LLDP Neighbors page to display information about devices
connected directly to the switch’s ports which are advertising information
through LLDP.
PARAMETERS
The following parameters are displayed on the LLDP Neighbors page:
◆ Local Port — The local port to which a remote LLDP-capable device is
attached.
◆ Chassis ID — An octet string indicating the specific identifier for the
particular chassis in this system.
◆ Remote Port ID — A string that contains the specific identifier for the
port from which this LLDPDU was transmitted.
◆ Port Description — A string that indicates the port’s description. If
RFC 2863 is implemented, the ifDescr object should be used for this
field.
◆ System Name — An string that indicates the system’s configures
assigned name.
◆ System Capabilities — The capabilities that define the primary
function(s) of the system. Refer to the following table:
◆ Management Address — The IPv4 address of the remote device. If no
management address is available, the address should be the MAC
address for the CPU or for the port sending this advertisement.
◆ TTL — Indicates the time (in seconds) the remote device’s information
should be treated as valid.
◆ LLDP Entry Number — The number of the LLDP table entry.
Table 10: LLDP System Capabilities
ID Basis Reference
Other —
Repeater IETF RFC 2108
Bridge IETF RFC 2674
WLAN Access Point IEEE 802.11 MIB
Router IETF RFC 1812
Telephone IETF RFC 2011
DOCSIS cable device IETF RFC 2669 and IETF RFC 2670
End Station Only IETF RFC 2011
