C
HAPTER
21
| General Security Settings
Port Isolation
– 116 –
PORT ISOLATION
Port Isolation provides port-based security and isolation of local ports. The
switch isolates port traffic by specifying those ports to which it can forward
or receive traffic.
PARAMETERS
The following parameters are displayed on the Port Isolation page:
◆ Port — Selects port and trunk interfaces. (Port Range: 1-26)
◆ Port Isolation List — Selects port and trunk interfaces to which traffic
can be forwarded and received. (Port Range: 1-26; Default: All ports
and trunks)
WEB INTERFACE
To configure Port Isolation settings:
1. Click Security, Port Isolation.
2. Select one or more ports to configure.
3. Select one or more ports to which traffic can be forwarded and
received.
4. Click Apply.
Figure 44: Port Isolation Settings
