C
HAPTER
6
| Link Aggregation
Configuring LACP
– 55 –
Current LACP Port Configuration
◆ Port – Port identifier. (Range: 1-26)
◆ LACP – Indicates ports that are enabled as LACP ports and if they are
passive or active.
◆ Aggregated – Indicates ports in a trunk that are members of an active
link.
WEB INTERFACE
To configure LACP settings:
1. Click Configuration, Link Aggregation, LACP Setting.
2. Enable LACP on the switch.
3. Specify the LACP System Priority to identify LAGs on the switch.
4. Click Apply.
Figure 14: LACP Port Configuration
