Operating panel devices
EST2 System Operations Manual 2.7
The operator also needs to know parameters for other keypad
entries, where:
• yyyy = year
• mm = month
• dd = day
• 01 - 07 = day of week
• hh = hour
• mm = minute
• ss = second
• nnnn = password, action number, sequence number
• tttt = time control
• PP = Priority
Note: Do not confuse a priority (PP) with the panel address (pp).
Selecting system functions on the 2-LCD
Table 2-5: Function switches
Function Switch Description
Status When pressed, the Status switch displays menus for viewing the status of
the general panel, the Signature Data Circuit (SDC), relays, LEDs, and
disabled devices.
Program When pressed, the Program switch displays menus for setting the time
and date, setting user passwords, configuring the RS-485 port, restarting
the system, and autoprogramming.
Enable When pressed, the Enable switch displays menus for enabling the
following system components: zones, zone messages, time controls, data
line, panels, actions, sequences, laptop, mapping.
Disable When pressed, the Disable switch displays menus for disabling the
following system components: zones, zone messages, time controls, data
line, panels, actions, sequences, laptop, mapping.
Activate When pressed, the Activate switch displays menus for activating the
following system components: output devices, actions, sequences,
primary smoke sensitivity levels, and alternate smoke sensitivity levels.
Restore When pressed, the Restore switch displays menus for returning the
following system components to the restored state: output devices,
actions, and sequences.
Reports When pressed, the Reports switch displays menus for obtaining system
sensitivity and history reports. Reports may be viewed on the main
controller display or sent to a printer.
Test When pressed, the Test switch activates the walk test function for testing
individual initiating device circuits.
