Generating reports
This section explains the functions of the Reports switch. In the
Reports mode, the 2-LCD offers two report options: sensitivity
and history. Both reports may be sent to either the 2-LCD
display or a printer.
Note: For a detailed explanation about the parameters of keypad
entries, see Making keypad entries, earlier in this chapter.
Viewing sensitivity reports
To view a sensitivity report:
1. At the 2-LCD, press Reports.
2. Enter a level 1, 2, or 3 password.
3. Enter 1 to choose a sensitivity report.
4. Enter 1 to send the report to the 2-LCD display.
5. Follow the instructions on the screen illustrated in Figure
2-14.
STDOP028.CDR
For All Press [ENT]
For Range ppaa [ENT]
[DEL] will terminate
Enter Choice
Figure 2-14: Sensitivity report instructions
Note:
If the fire alarm control panel has been on for less than 15
minutes, the 2-LCD will display the screen in Figure 2-15.
STDOP045.CDR
Sensitivity Report
is only valid after
15 minutes of opera-
tion. Press [del].
Figure 2-15: Sensitivity report delay
The parameters “ppaa” stand for the panel and device address.
For example, a detector at address 56 on an MCM Signature
data circuit would require 0156 for its entry.
Figure 2-16 illustrates a typical sensitivity report on the 2-LCD.
