Operating panel devices
EST2 System Operations Manual 2.39
Figure 2-23 illustrates the 2-LCD display during the test mode.
STDOP034.CDR
13:18:12 M002 @13:27
Open Fault 0030
System in Test Mode
Figure 2-23: Typical test mode screen
Ending the test function
The Test function ends through operator input or automatic
system response and resets the fire alarm control panel.
To end the Test function manually:
1. At the 2-LCD, press Test.
2. Press Delete.
The test function will automatically end if you let 30 minutes
pass without testing a device. The 2-LCD provides a reminder of
the 30-minute test window, as seen in Figure 2-22.
See the site-specific information, provided with the panel, for
customized test functions.
