EFI E-42B - Removing E-42 B from Furniture

SERVICING THE E-42B WITH FURNITURE 128
REMOVING THE E-42B FROM THE FURNITURE
Never lift the E-42B by grasping the top panel. The top panel does not support the weight of
the system.
1 Make sure that the E-42B is shut down and that all the cables are removed from the back of
the E-42B.
2 Remove the cable cover and disconnect the two monitor cables (power and video):
• Power from the back of the monitor and from the wall outlet
•
Video from the back of the monitor and from the back of the E-42B
Video cable
Cable cover
Power cable
