S
ERVICING
THE
E-42B
WITH
FU
RNITURE
129
3
Remov
e the thumbscrew
s that attach th
e E-42B stability br
ack
et to the
stand.
4
Lift the br
acket and gently pul
l
the E-42B
away fr
om the table top.
Make sure to pull the
E-42B out just enough so that the front panel of the E-42B is aligned
with the back edge of the table top
.
Stability bracket
Thumbscrew
s
128
130
