20
For
more information on PV array sizing, scan the following QR code:
NOTE:
For all modules, the calculations need to be performed or verified by using a string
calculator or consulting a professional.
DANGER:
DAMAGE WILL OCCUR if the string voltage on a cold, sunny morning exceeds the
inverter’s maximum input voltage of 600V!
The array can have a higher Imp than the 26A/15A specified, but the MPPTs will not
make full use of the extra current. Having an array that can produce more current
than the MPPTs can utilize is useful for increasing morning, winter, or cloudy day
solar production. An Imp higher than 31A/19A will cause damage to the inverter.
NOTE:
The array can have a higher Imp than the 26A/15A specified, but the MPPTs will not
make full use of the extra current. Having an array that can produce more current
than the MPPTs can utilize is useful for increasing morning, winter, or cloudy day
solar production. An Imp higher than 31A/19A will cause damage to the inverter.
