EG4 FLEXBOSS21 - Technical Specifications

1
1. TECHNICAL SPECIFICATIONS
AC INPUT DATA
NOMINAL AC VOLTAGE
120/240VAC; 120/208VAC (L1/L2/N required)
FREQUENCY
60 Hz Default | 50 Hz Capable
MAX. AC CURRENT
50A @ 240V | 57.7A @ 208V
MAX. AC INPUT POWER
12kW
MAX. AC BYPASS
90A
AC GRID OUTPUT DATA
MAX. OUTPUT CURRENT
66.7A
OUTPUT VOLTAGE
120/240VAC; 120/208VAC (L1/L2/N required)
OPERATING VOLTAGE RANGE
180 – 270VAC
NOMINAL POWER OUTPUT
16kW @ 240V | 13.8kW @ 208V
OUTPUT FREQUENCY
60 Hz Default| 50 Hz Capable
POWER FACTOR
0.99 @ Full Load
REACTIVE POWER ADJUST RANGE
(-0.8) – (+0.8) Leading Adjustable
PEAK POWER (SURGE CAPACITY)
24kW
(0.5 sec)
18kW
(1 sec)
15kW
(6 min)
13.3kW
(12min)
THD @FULL LOAD
<5%
TRANSFER TIME
20 ms (Default), 10 ms (Configurable) | Parallel – 20 ms
BACKUP/UPS AC OUTPUT DATA
RATED OUTPUT CURRENT (240 | 208VAC)
50A | 57.7A
NOMINAL OUTPUT VOLTAGE
120/240 | 120/208VAC
RATED OUTPUT POWER
12kW @240VAC | 12kW @208VAC
PEAK POWER
18kW
(1 sec)
15kW
(6 min)
13.3kW
(12 min)
Without PV:
13.3kW
(12 min)
OPERATING FREQUENCY
50/60 Hz
THDV (TOTAL HARMONIC DISTORTION VOLTAGE)
<5%
TRANSFER TIME
20 ms (Default), 10 ms (Configurable) | Parallel: 20 ms
PV INPUT DATA
NUMBER OF MPPTS
3
INPUTS PER MPPT
2 (MPPT 1) | 2 (MPPT 2) | 1 (MPPT 3)
MAX. USABLE INPUT CURRENT
26A (MPPT 1) | 26A (MPPT 2) | 15A (MPPT 3)
MAX. SHORT CIRCUIT INPUT CURRENT
31A (MPPT 1) | 31A (MPPT 2) | 19A (MPPT 3)
DC INPUT VOLTAGE RANGE
100 – 600VDC
UNIT STARTUP VOLTAGE
140VDC
MPPT OPERATING VOLTAGE RANGE
120 – 440VDC
NOMINAL MPPT VOLTAGE
360VDC
MAX. UTILIZED SOLAR POWER
21kW
MAX. RECOMMENDED SOLAR INPUT
24kW
EFFICIENCY
CEC
96.9%
MAX. EFFICIENCY (PV TO GRID)
97%
MAX. EFFICIENCY (BATTERY TO GRID)
94%
MAX. EFFICIENCY (PV TO BATTERY)
94.5%
IDLE CONSUMPTION (STANDBY MODE)
<60W
