Chapter 2 Conguring from the monitor screen
Save Settings Data
1. Connect a USB storage device to the USB downstream port of the monitor.
2
4
3
2. Enter the password.
The password is blank by default. Set the password as necessary.
3. Select “Execute”. The settings data are saved.
4. Select “Run” for “Remove USB Storage”.
When the Removing Complete screen is displayed, select “OK”.
5. Remove the USB storage device.
Attention
• Some of the settings cannot be saved.
• If you forget the password that you specied when saving the data, you will no longer be able to load the settings.
Note
• Saved le name: Backupyyyymmdd.duraconf (yyyymmdd is the save date)
To Next Page
