E L A N H O M E S Y S T E M S S1616A AMPLIFIER MODE
© ELAN Home Systems 2012 | All rights reserved.
ELAN Special Application - IR Control
Prerequisites: Factory Default the amp and set to ELAN Mode.
Channel Range: Set to 1 to 16.
Connect IR input.
See:
Restore Defaults on page 29, Operating Mode Menu on page 23
Channel Range on page 34
Link / Unlink commands in Appendix A: IR Command Set
With the IR input connected you can control the S1616A's volume output directly.
Instead of sending ELAN zone volume commands to the ELAN A/V Controller, send S1616A's Channel 1
Volume Up/Down or Channel 2 Volume Up/Down IR Commands to the S1616A.
ELAN Special Application - IR Control (additional chassis)
Prerequisites: Factory Default the S1616As and set to ELAN Mode.
Channel Range: Set chassis one to 1-16 and chassis two to 17 – 32.
Connect IR Loop between the chassis.
Instead of sending ELAN zone volume commands to the ELAN A/V Controller, send S1616A's Channel 17
Volume Up/Down or Channel 18 Volume Up/Down IR Commands to the S1616A.
Since Channel Range is set to 17 - 32, you must control the channel's volume using different commands.
When a S1616A Channel Range is set to 17 - 32, the S1616A is the second chassis in a two S1616A
chassis system.
