Multiple Bus Inputs with Stereo and Mono Outputs
ELAN Special Application
Scenario: Zone one has four stereo speaker pairs, zone two has two stereo pairs and two
summed mono speakers, zones three and four have a single summed mono speaker each.
Prerequisites: Factory Default the amp and set to ELAN or Normal Mode.
Input Select Menu:
Zone 1 - Channels 1, 3, 5, 7 - Set Inputs to 1 Bus A
Zone 1 - Channels 2, 4, 6, 8 - Set Inputs to 2 Bus A
Zone 2 - Channels 9, 11 - Set Inputs to 9 Bus B
Zone 2 - Channels 10, 12 - Set Input to 10 Bus B
Zone 2 - Channel 13 - Set Input to 9+10 Mono Bus B
Zone 2 - Channel 14 - Set Input to 9+10 Mono Bus B
Zone 3 - Channel 15 - Set Input to 13+14 Mono Bus F
Zone 4 - Channel 16 - Set Input to 15+16 Mono Bus H
See:
Restore Defaults on page 29, Operating Mode Menu on page 23
Channel Range Menu on page 34, Input Select Menu on page 17
Also see Analog / Digital Bus Input information on page 25
Volume is adjusted by the ELAN A/V Controller.
(Wiring example on next page.)
