E L A N H O M E S Y S T E M S S1616A AMPLIFIER MODE

Page 7

S1616A Amplifier Mode Features

 Class D Digital Technology

Provides clean, transparent audio amplification while greatly reducing power

consumption

 50 Watts Per Channel

Easily produces 50W/Ch into an 8 ohm load and 75W/Ch into 4 ohm loads

 Automatic Clipping Eliminator (ACE)

This S1616A limiter constantly monitors the amplified output to prevent signal clipping

 Automatic Volume Reduction (AVR)

This S1616A limiter constantly monitors the overall output to prevent over-driving the

amplifier

 Intelligent Load Monitoring

The S1616A automatically detects load faults and shuts down only the affected channels,

thereby protecting speakers, wiring and the amplifier itself

 Multiple Bus Inputs

The S1616A can utilize up to 8 stereo bus inputs to allow sharing a single audio source

between multiple speaker outputs (no jumper wires required)

 Buffered Loop Outputs

Every input channel has a buffered loop output that allows the user to easily share audio

sources with other equipment

 IR Controllable

Each channel can be independently controlled via IR commands

 USB Port

Allows easy in-field firmware updates

 Rack Mount Brackets Included

No need to worry about field compatibility

 Available in 240 Volt Version

 cTUVus, CE

, and C-Tick Certified
