Aquastorm 200
1-18 Overview
Demisting Filter
Angle Adjustable Transition Conveyor
Entrance End View with Maintenance Panel Removed
Exhaust Demisting Filter for wet sections
reduces water consumption and chemical usage.
The filters are strategically located; just before
the prewash section at the entrance end of the
conveyor, and in the Enhanced Chemical Isolation
Section.
Angle Adjustable Transition
Conveyor
A 91.44 cm (36 inch), angle adjustable transition
conveyor that adjusts from a horizontal height
of 91.44 cm (36 inches) to an inclined maximum
of 132 cm (52 inches). Complies to SMEMA
(Surface Mount Equipment Manufacturers'
Association) height requirements of 94 to 96.5
cm (37 to 38 inches). Allows in-line, direct feed
capabilities immediately following automatic wave
soldering or reflow soldering processes to the
Aquastorm 200™ aqueous cleaning system.
