Elmo L-12 User Manual

17
English
BASIC
OPERATIONS

Adjusting the brightness
Press the [ / ] button on the operating panel or the
[
/ ] buttons on the remote control to adjust the image
brightness.
The following two adjustment modes can be set by selecting
[Brightness] from the menu on the screen.
Automatic brightness adjustment
( [ ]
→
[ ]
→
[ ]
→
[Auto] )
To ensure a constant degree of brightness, the brightness of
the image changes automatically according to the brightness
of the shooting environment. Use the [
/ ] button on the
operating panel or the [
/ ] buttons on the remote control
to change the automatic brightness adjustment.
Brightness of the screen is the same
Brightness
>Auto
Manual

Elmo L-12 Specifications

General

Sensor type	CMOS
Image freeze	-
White balance	Auto, Manual
Maximum frame rate	30 fps
Optical sensor size	1/2.8 \
Effective sensor resolution	3.4 MP
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1920 x 1080 (HD 1080)
Auto focus	Yes
Digital zoom	8 x
Optical zoom	12 x
Shooting area (WxD)	420 x 313 mm
Maximum focal length (f)	48 mm
USB connector type	USB Type-A
USB 2.0 ports quantity	2
VGA (D-Sub) input ports	1
Lamp type	LED
Product color	White
Camera movement	Manual
AC input voltage	100-240 V
Operating voltage	12 V
Power supply type	AC
Power consumption (typical)	17.5 W
Cables included	AC, USB

Weight and Dimensions

Depth	373.5 mm
Width	355 mm
Height	426.5 mm
Weight	3200 g
Dimensions folded (WxDxH)	195 x 294 x 469 mm
