Elmo L-12 User Manual

26
English
BASIC
OPERATIONS
Suppport Function Setting
Highlight
Icon Name Selection Item Function
Darkness
Darken
To set the darkness of a dark section. The dark
section becomes darker when [
] is selected,
and becomes more visible when [ ] is selected.
Lighten
Exit
Size
Lengthen Height
(stretch)
To change the size of the highlighted display area.
Shorten Height
Lengthen Width
(stretch)
Shorten Width
Exit
Exit
Mask
Icon Name Function
Exit
Scroll
Icon Name Function
x2 To set the digital zoom magnification to 2x when the Scroll icon is selected.
x3 To set the digital zoom magnification to 3x when the Scroll icon is selected.
x4 To set the digital zoom magnification to 4x when the Scroll icon is selected.
Exit
Compare Picture
Icon Name Function
Prev Picture To show the previous picture.
Next Picture To show the next picture.
Exit

Elmo L-12 Specifications

General

Sensor type	CMOS
Image freeze	-
White balance	Auto, Manual
Maximum frame rate	30 fps
Optical sensor size	1/2.8 \
Effective sensor resolution	3.4 MP
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1920 x 1080 (HD 1080)
Auto focus	Yes
Digital zoom	8 x
Optical zoom	12 x
Shooting area (WxD)	420 x 313 mm
Maximum focal length (f)	48 mm
USB connector type	USB Type-A
USB 2.0 ports quantity	2
VGA (D-Sub) input ports	1
Lamp type	LED
Product color	White
Camera movement	Manual
AC input voltage	100-240 V
Operating voltage	12 V
Power supply type	AC
Power consumption (typical)	17.5 W
Cables included	AC, USB

Weight and Dimensions

Depth	373.5 mm
Width	355 mm
Height	426.5 mm
Weight	3200 g
Dimensions folded (WxDxH)	195 x 294 x 469 mm
