Elmo L-12 User Manual

45
English
ADVANCED
OPERATIONS
Displaying a picture full-screen
You can display a picture you selected from the thumbnails (list of pictures/movies) full-screen.
䎶䎧䎒䎳䏌䏆䏗䏘䏕䏈
䎓䎓䎔䎒䎓䎓䎖
<Thumbnail images> <Full-screen picture>
Basic operations
①
Show in the Thumbnail Menu the icon for displaying the list of pictures.
Press the
[
] button on the operating panel to display
the Thumbnail Menu.
Then, the current status of the selection is displayed at the
button right of the screen.
(1) If you see [ ] in the menu, the list of pictures
has already been displayed.
(2)
If you see [
] in the menu, press the [ ] or
[
] button on the operating panel to move the
cursor to [
] and then press the [ ] button.
You can display the list of pictures.
Or a list of images can be displayed with the
[
] button on the remote control.
(3)
Press the [
] button again to hide the
Thumbnail Menu.
SD/Picture
001/003
Thumbnail menu

Elmo L-12 Specifications

General

Sensor type	CMOS
Image freeze	-
White balance	Auto, Manual
Maximum frame rate	30 fps
Optical sensor size	1/2.8 \
Effective sensor resolution	3.4 MP
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1920 x 1080 (HD 1080)
Auto focus	Yes
Digital zoom	8 x
Optical zoom	12 x
Shooting area (WxD)	420 x 313 mm
Maximum focal length (f)	48 mm
USB connector type	USB Type-A
USB 2.0 ports quantity	2
VGA (D-Sub) input ports	1
Lamp type	LED
Product color	White
Camera movement	Manual
AC input voltage	100-240 V
Operating voltage	12 V
Power supply type	AC
Power consumption (typical)	17.5 W
Cables included	AC, USB

Weight and Dimensions

Depth	373.5 mm
Width	355 mm
Height	426.5 mm
Weight	3200 g
Dimensions folded (WxDxH)	195 x 294 x 469 mm
