Elmo L-12 User Manual

18
English
BASIC
OPERATIONS
Manual brightness adjustment
([ ]
→
[ ]
→
[ ]
→
[Manual])
Use the [ / ] buttons on the operating panel or the
[
/ ] buttons on the remote control to change the level
of brightness. The brightness of the image will not change
automatically in response to the brightness of the shooting
environment.
Brightness of the screen is different
• Factory setting is set to [Auto].
• By setting [ ]
→
[ ]
→
[On], the setting details are displayed on the screen.
• To return to the factory settings, press the [ / ] buttons on the
operating panel at the same time, or select [Rst Brightness] from the
menu.
• In places where the object is exposed to bright sunlight (e.g. near a
window), or extremely bright lights, the brightness of the screen may not
dim sufficiently, even when the [ ] button on the operating panel or
the [ ] button on the remote control is pressed.
In such cases, to adjust the amount of light, close the curtains or move
the object away from the light.
N o t e
Brightness
>Auto
Manual

Elmo L-12 Specifications

General

Sensor type	CMOS
Image freeze	-
White balance	Auto, Manual
Maximum frame rate	30 fps
Optical sensor size	1/2.8 \
Effective sensor resolution	3.4 MP
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1920 x 1080 (HD 1080)
Auto focus	Yes
Digital zoom	8 x
Optical zoom	12 x
Shooting area (WxD)	420 x 313 mm
Maximum focal length (f)	48 mm
USB connector type	USB Type-A
USB 2.0 ports quantity	2
VGA (D-Sub) input ports	1
Lamp type	LED
Product color	White
Camera movement	Manual
AC input voltage	100-240 V
Operating voltage	12 V
Power supply type	AC
Power consumption (typical)	17.5 W
Cables included	AC, USB

Weight and Dimensions

Depth	373.5 mm
Width	355 mm
Height	426.5 mm
Weight	3200 g
Dimensions folded (WxDxH)	195 x 294 x 469 mm
