Elmo L-12 User Manual

4
English
BUNDLED
ITEMS
1.
BUNDLED ITEMS
1
The items below are included with this product. If any item is missing, contact the
dealer from whom you purchased this product.
Anti-glare sheet
P.13
AAA batteries
P.12
(for Remote control)
Image Mate CD-ROM
P.13
RGB cable
P.8
Stage
P.13
Remote control
P.12
USB cable
P.8
(for Connecting to PC)
Image Mate
Installation
Manual
Image Mate
Installation Manual
Basic
Startup
Guide
Basic Startup Guide
3S Service
Registration
Form
3S Service Registration
Form
※ 1
Operation
Assistance
Label
Operation Assistance
Label
※ 1
3S Service
Registration
Statement
3S Service Registration
Statement
※ 1
Warranty
Warranty
※ 1, ※ 2
3S Assurance
Guarantee Label
3S Assurance Guarantee
Label
※ 1
※ 1 Japan only
※ 2 N. America only
Strap
P.13
(for Remote control)
Dust cover
P.13
AC cord
P.14
AC adapter
P.7
Instruction manual
CD-ROM
P.13
Document camera
P.5

Elmo L-12 Specifications

General

Sensor type	CMOS
Image freeze	-
White balance	Auto, Manual
Maximum frame rate	30 fps
Optical sensor size	1/2.8 \
Effective sensor resolution	3.4 MP
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1920 x 1080 (HD 1080)
Auto focus	Yes
Digital zoom	8 x
Optical zoom	12 x
Shooting area (WxD)	420 x 313 mm
Maximum focal length (f)	48 mm
USB connector type	USB Type-A
USB 2.0 ports quantity	2
VGA (D-Sub) input ports	1
Lamp type	LED
Product color	White
Camera movement	Manual
AC input voltage	100-240 V
Operating voltage	12 V
Power supply type	AC
Power consumption (typical)	17.5 W
Cables included	AC, USB

Weight and Dimensions

Depth	373.5 mm
Width	355 mm
Height	426.5 mm
Weight	3200 g
Dimensions folded (WxDxH)	195 x 294 x 469 mm
