Elmo L-12 User Manual

53
English
ADVANCED
OPERATIONS
3-2 Saving data stored on an SD card to
PC via USB cable
CAUTION
• Set [ ] (USB Mode) to [Mass Storage] from the Preferences menu on the screen.
P.24
• Insert the SD card with the label facing up. Forcing it into the slot with the wrong side up may cause
a malfunction.
By connecting this equipment to a PC via USB, you can save the image data stored on the SD card to the
PC.
The operating system (OS) for the connected PC should be Microsoft Windows 2000 (SP4 or later),
Windows XP (SP2 or later), Windows Vista or Windows 7.
①
Turn on the equipment and the PC.
②
Connect the equipment to the PC with the supplied USB cable.
• When you connect the equipment to the PC for the first time, the required drivers are
installed automatically using the plug-and-play function of Windows. From the second time
and thereafter, the drivers are not installed again.
N o t e

Elmo L-12 Specifications

General

Sensor type	CMOS
Image freeze	-
White balance	Auto, Manual
Maximum frame rate	30 fps
Optical sensor size	1/2.8 \
Effective sensor resolution	3.4 MP
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1920 x 1080 (HD 1080)
Auto focus	Yes
Digital zoom	8 x
Optical zoom	12 x
Shooting area (WxD)	420 x 313 mm
Maximum focal length (f)	48 mm
USB connector type	USB Type-A
USB 2.0 ports quantity	2
VGA (D-Sub) input ports	1
Lamp type	LED
Product color	White
Camera movement	Manual
AC input voltage	100-240 V
Operating voltage	12 V
Power supply type	AC
Power consumption (typical)	17.5 W
Cables included	AC, USB

Weight and Dimensions

Depth	373.5 mm
Width	355 mm
Height	426.5 mm
Weight	3200 g
Dimensions folded (WxDxH)	195 x 294 x 469 mm
