Elmo L-12 User Manual

37
English
ADVANCED
OPERATIONS
3.
ADVANCED OPERATIONS
3
3-1 Using an SD card/USB flash drive
With this equipment, you can save a camera image as a picture or movie on an SD card or USB flash drive.
You can also display the data stored on the SD card or USB flash drive on the screen.
Before you begin, insert a commercially available SD card or USB flash drive into the corresponding slot on
the side panel.
•
SD card
-
The SDXC card cannot be used.
-
Formatting the SD card with this product before you use is recommended.
-
Using the SD card to record movies is recommended.
-
Using the SD card class 6 or higer is recommended.
• USB flash drive
-
Supports the USB flash drive up to 32GB.
-
Formatting the USB flash drive with this product before you use is recommended.
• It may take some time to recognize the memory card after inserting it or to save images to
the memory card.
• Please do not remove the memory card while recording, playing or using education support
function when the main unit is accessing the memory card.
N o t e

Elmo L-12 Specifications

General

Sensor type	CMOS
Image freeze	-
White balance	Auto, Manual
Maximum frame rate	30 fps
Optical sensor size	1/2.8 \
Effective sensor resolution	3.4 MP
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1920 x 1080 (HD 1080)
Auto focus	Yes
Digital zoom	8 x
Optical zoom	12 x
Shooting area (WxD)	420 x 313 mm
Maximum focal length (f)	48 mm
USB connector type	USB Type-A
USB 2.0 ports quantity	2
VGA (D-Sub) input ports	1
Lamp type	LED
Product color	White
Camera movement	Manual
AC input voltage	100-240 V
Operating voltage	12 V
Power supply type	AC
Power consumption (typical)	17.5 W
Cables included	AC, USB

Weight and Dimensions

Depth	373.5 mm
Width	355 mm
Height	426.5 mm
Weight	3200 g
Dimensions folded (WxDxH)	195 x 294 x 469 mm
