English

BASIC

OPERATIONS

2-4 Setting Changes

Various settings for this unit are changed through the menu (characters and icons) displayed on the screen.



Changing a Setting

①

Press the [ ] button on the operating panel to display the menu on the screen, and then use the

[

] buttons to move the cursor to the icon you want to operate or set.

②

Press the [ ] button to select the function to be changed.

Select

Front operating panel

Move the cursor up

Move the cursor left Move the cursor right

Display/hide the

menu on the screen

Move the cursor down

Camera Controls



List of the Menus

Highlight

Press

Press [Select]

Main unit settings

Support Function

P.22 P.22 P.22P.22 P.23

P.23

P.24 P.24 P.24

P.23 P.23 P.23P.23 P.23

P.24

P.25 P.25 P.25 P.25

P.25 P.25 P.25

P.24

P.25

P.24

P.25

P.24

※

To go back a layer or to hide the menu, select [ ] and press the [ ] button.

Questions and Answers:

Need help?

Do you have a question about the Elmo L-12 and is the answer not in the manual?

Elmo L-12 Specifications

General

Sensor type	CMOS
Image freeze	-
White balance	Auto, Manual
Maximum frame rate	30 fps
Optical sensor size	1/2.8 \
Effective sensor resolution	3.4 MP
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1920 x 1080 (HD 1080)
Auto focus	Yes
Digital zoom	8 x
Optical zoom	12 x
Shooting area (WxD)	420 x 313 mm
Maximum focal length (f)	48 mm
USB connector type	USB Type-A
USB 2.0 ports quantity	2
VGA (D-Sub) input ports	1
Lamp type	LED
Product color	White
Camera movement	Manual
AC input voltage	100-240 V
Operating voltage	12 V
Power supply type	AC
Power consumption (typical)	17.5 W
Cables included	AC, USB
