BASIC
OPERATIONS

Turning the illumination ON/OFF
ON
OFF
ON
OFF
Illumination lamp
The illumination light can be turned ON/OFF by sliding the illumination light switch.
・
[ON] : The illumination light turns on.
・
[OFF] : The illumination light turns off.
CAUTION
• To take shots of people, turn the illumination light switch to OFF.
•
Make sure that the light from the illumination light does not shine directly into your e
yes.
•
This product is equipped with a high-brightness LED light.
You can safely use the light to light up
objects, however its brightness will gradually diminish with long-term use. This is not a malfunction
of the light, but a feature of LED performance.
• Do not touch the illumination light while it is on as it may become very hot.

Elmo L-12 Specifications

General

Sensor type	CMOS
Image freeze	-
White balance	Auto, Manual
Maximum frame rate	30 fps
Optical sensor size	1/2.8 \
Effective sensor resolution	3.4 MP
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1920 x 1080 (HD 1080)
Auto focus	Yes
Digital zoom	8 x
Optical zoom	12 x
Shooting area (WxD)	420 x 313 mm
Maximum focal length (f)	48 mm
USB connector type	USB Type-A
USB 2.0 ports quantity	2
VGA (D-Sub) input ports	1
Lamp type	LED
Product color	White
Camera movement	Manual
AC input voltage	100-240 V
Operating voltage	12 V
Power supply type	AC
Power consumption (typical)	17.5 W
Cables included	AC, USB

Weight and Dimensions

Depth	373.5 mm
Width	355 mm
Height	426.5 mm
Weight	3200 g
Dimensions folded (WxDxH)	195 x 294 x 469 mm
