Elmo L-12 User Manual

67
English
ADVANCED
OPERATIONS
Menu descriptions
Thumbnail Mode
Icon Name Selection Item Function
Prev Page To move to the previous thumbnail page.
Next Page To move to the next thumbnail page.
USB Flash Drive
Movie
To switch the data displayed as thumbnails
between movies and pictures.
Next Menu To move to the next menu page.
Memory Lock
Lock/Unlock
To lock (set as protected) or unlock (set as
unprotected) the selected image.
Lock All To lock (set as protected) all thumbnail images.
Unlock All
To unlock (set as unprotected) all thumbnail
images.
Delete
Yes To delete the selected image.
No To cancel deletion.
Format
Yes To format the SD card.
No To cancel formatting.
Prev Menu To move to the previous menu page.

Elmo L-12 Specifications

General

Sensor type	CMOS
Image freeze	-
White balance	Auto, Manual
Maximum frame rate	30 fps
Optical sensor size	1/2.8 \
Effective sensor resolution	3.4 MP
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1920 x 1080 (HD 1080)
Auto focus	Yes
Digital zoom	8 x
Optical zoom	12 x
Shooting area (WxD)	420 x 313 mm
Maximum focal length (f)	48 mm
USB connector type	USB Type-A
USB 2.0 ports quantity	2
VGA (D-Sub) input ports	1
Lamp type	LED
Product color	White
Camera movement	Manual
AC input voltage	100-240 V
Operating voltage	12 V
Power supply type	AC
Power consumption (typical)	17.5 W
Cables included	AC, USB

Weight and Dimensions

Depth	373.5 mm
Width	355 mm
Height	426.5 mm
Weight	3200 g
Dimensions folded (WxDxH)	195 x 294 x 469 mm
