Drip loops must be made in all cables
Note:
l For security, once fitted, the rear cover can only be removed using a tool, such as a small, flat bladed
screwdriver.
2.6 ems25 series thermal fuse (CQC only)
The ems25 and ems25
+
housings are designed with an aperture for a thermal fuse to be located.
The thermal fuse is a part of a main harness which is supplied by elstat.
The location for the 4-way mains connector (harness) and thermal fuse are shown below:
ems25+ and ems25advanced / General Use
