To mount an ems25 series controller, insert the ems controller into the aperture as shown in the following example.
Then, secure the ems controller into position using the supplied display side-clips as shown below.
Note:
l Decorative trimkits are supplied separately.
l See "ems decorative trims" on page 84
l The large decorative trim kits are screwed into place.
Cable routing to the ems controller is critical as water can trace or follow the cable downwards. Therefore, immediately prior
to the connection to the controller, a drip loop must be formed in all wiring as shown below.
ems25+ and ems25advanced / General Use
13 of 89
