11 annexe I UL information
Note:
l This annexe applies to ems25+ controllers, 120VAC only
electrical ratings
inputs
control input item input rating terminals
supply 120VAC, 3VA, 50/60Hz
(L) line in (7)
(N) neutral (5)
temperature sensor input
5Vdc, Limited Energy Circuit, 15W or less
(class 2)
appliance sensor (3)
door / sensor input
5Vdc, Limited Energy Circuit, 15W or less
(class 2)
condenser sensor (2)
auxiliary input
5Vdc, Limited Energy Circuit, 15W or less
(class 2)
door switch (1)
outputs
model type rating load type cycles terminal
all models
compressor relay
(K3)
6FLA / 36LRA
120VAC
motor 100K
(L) line in (7)
compressor (6)
all models
lights relay
(K2)
120VAC
250W
ballast 6K
(L) line in (7)
lights (4)
11.1 ems25
+
rear view (input reference)
1. door switch
2. condenser sensor
3. appliance sensor
4. lights out
5. neutral
6. compressor out
7. line in
8. microRMD and parameter programming port
ems25+ and ems25advanced / General Use
