14 ems decorative trims
Decorative trim kits are supplied separately from ems25 series controllers in order to allow for custom installation.
Note:
l Ensure that a matching quantity of decorative trims are ordered with controllers.
Two kit sizes are available - small and large - in three varieties as described in this section.
14.1 small decorative trim kit
Available in black and black with 'The Coca-Cola Company' branding.
The small decorative trim kit consists of a small decorative trim, a green gasket and two side clips, as illustrated:
14.2 fitting the small decorative trim kit
1. Fit the smalldecorative trim and gasket to the controller as shown:
ems25+ and ems25advanced / General Use
84 of 89
