ELTEX MES3108 - 5.15.8 G.8032 v2 (ERPS) protocol configuration

102 MES3000 Ethernet switch series
secondary-port
{gigabitethernet gi_port |
tengigabitethernet te_port |
port-channel group }
gi_port: (1..8/0/1..24);
te_port: (1..8/0/1..4);
group: (1..24)
Select the secondary switch port included in the ring.
role {master | transit} level
level_id
level_id: (0..1)
Select the switch role in the configured domain and ring.
Possible roles:
- master—device is the master node
- transit—device is the transit node
- edge—adjacent node that belongs to both primary and
secondary rings
- sub-edge—auxiliary adjacent node, that belongs to both primary
and secondary rings
role {edge | sub-edge}
-
EXEC mode commands
Command line request in EXEC mode appears as follows:
console#
Table 5.100 —EXEC mode commands
Command
Value
Action
show eaps [domain domain_id
[ring ring_id]]
domain_id: (0..63);
ring_id: (1..15)
Request the information on the state of domains and EAPS rings.
- domain_id—EAPS domain identifier;
- ring_id—EAPS ring identifier.
5.15.8 G.8032v2 (ERPS) protocol configuration
ERPS ( Ethernet Ring Protection Switching) protocol allows to increase stability and robustness of
data network with ring topology by decreasing the restoration time after the failure. Restoration time
does not exceed 1 second, which is substantially lower than the network reconstruction in case of
spanning tree family of protocols.
Global configuration mode commands
Command line request in global configuration mode appears as follows:
console(config)#
Table 5.101 —Global configuration mode commands
Command
Value/Default value
Action
erps
-
Enable ERPS protocol operation.
no erps
Disable ERPS protocol operation.
erps vlan vlan_id
vlan_id: (1..4094)
Create ERPS ring with VLAN R-APS identifier that will be used for
service information transmission and entering the ring
configuration mode.
no erps vlan vlan_id
Remove ERPS ring with vlan_id identifier.
Ring configuration mode commands
Command line request in ring configuration mode appears as follows:
console(config-erps)#
Table 5.102 —ERPS ring configuration mode commands
Command
Value/Default value
Action
protected vlan add vlan_list
vlan_list:(2..4094, all)
Add VLAN range into the secure VLAN list.
protected vlan remove
vlan_list
vlan_list:(2..4094, all)
Remove VLAN range from the secure VLAN list.
- vlan_list—VLAN list for deletion.
