MES3000 Ethernet switch series 171
port security mode
{maxaddresses | lock}
-/lock
Enable the MAC address learning restriction mode for the
configured interface.
- max-addresses—remove the current dynamically learnt
addresses, related to this interface. Learning of address maximum
quantity for the port is enabled. Repeated learning and aging is
enabled.
- lock—save the current dynamically learnt addresses related to
the interface into the file and deny the new address learning and
the aging of the already learnt addresses.
no port security mode
Restore the default value.
EXEC mode commands
Command line request in EXEC mode appears as follows:
console>
Table 5.199 —EXEC mode commands
Command
Value
Action
show ports security
{gigabitethernet gi_port |
tengigabitethernet te_port |
port-channel group}
gi_port: (1..8/0/1..24);
te_port: (1..8/0/1..4);
group: (1..24)
Show security function settings for the selected interface.
show ports security addresses
{gigabitethernet gi_port |
tengigabitethernet te_port |
port-channel group}
gi_port: (1..8/0/1..24);
te_port: (1..8/0/1..4);
group: (1..24)
Show the current dynamic addresses for the blocked ports.
set interface active
{gigabitethernet gi_port |
tengigabitethernet te_port |
port-channel group}
gi_port: (1..8/0/1..24);
te_port: (1..8/0/1..4);
group: (1..24)
Activate the interface, disabled by the port security function (this
command is available to privileged users only).
Example execution of commands
 Enable security function for Ethernet interface 15. Set the port learning restriction for port 1.
After the MAC address has been learnt, block the new address learning function for the
interface and drop packets with unknown source MAC address. Save learnt address into file.
console# configure
console(config)# interface gigabitethernet 1/0/15
console(config-if)# port security max 1
 Connect the client to port and learn the MAC address.
console(config-if)# port security discard
console(config-if)# port security mode lock
5.24.2 Port-based client authentication (IEEE 802.1x standard)
5.24.2.1 Basic authentication
Authentication based on IEEE 802.1x standard enables authentication of switch users via the
external server using the port that the client is connected to. Only authenticated and authorized users will
be able to send and receive the data. Port user authentication is performed by RADIUS server and EAP
(Extensible Authentication Protocol).
Global configuration mode commands
Command line request in global configuration mode appears as follows:
