MES3000 Ethernet switch series 51
1. The switch downloads the text file and reads the firmware file name on TFTP server.
2. The switch downloads the first block (512 bytes) of the firmware image file from TFTP server
with the firmware version.
3. The switch compares firmware image file version, downloaded from TFTP server, with the
active image of the switch firmware. If they differ, the switch will download the firmware
image from TFTP server and make it active.
4. When the firmware image download is finished, the switch will restart.
Automatic configuration
The switch will automatically execute the configuration process based on DHCP, if the following
conditions are met:
1. Automatic configuring is enabled in configuration.
2. DHCP server reply contains TFTP server IP address (DHCP Option 66) and configuration file
name (DHCP Option 67) in ASCII format.
Resulting configuration file will be added to the current (running) configuration.
If the user has enabled automatic saving ('boot host auto-save' command), the current
(running) configuration will be copied into the initial configuration (startup).
Global configuration mode commands
Command line request in global configuration mode appears as follows:
console(config)#
Table 5.24 —System management commands in global configuration mode
Enable automatic configuration based on DHCP.
Enable automatic saving of the current configuration into initial
configuration after getting it via TFTP.
Enable automatic update based on DHCP.
Enable forced configuration load on the next switch startup.
Privileged EXEC mode commands
Command line request in privileged EXEC mode appears as follows:
console#
Table 5.25 —System management commands in privileged EXEC mode
View automatic update and configuration settings.
