The green-ethernet mode is enabled for the MES3000 series switches by default.
Permissible measurement accuracy is defined by line parameters variety and amounts up to
6m.
Privileged EXEC mode commands
Command line request in privileged EXEC mode appears as follows:
console#
Table 5.185 —Copper-wire cable diagnostics commands
Command
Value
Action
test cable-diagnostics tdr
interface {gigabitethernet
gi_port | tengigabitethernet
te_port}
gi_port: (1..8/0/1..24);
te_port: (1..8/0/1..4).
Perform the virtual cable testing for the selected interface.
EXEC mode commands
Command line request in EXEC mode appears as follows:
console>
Table 5.186 —Copper-wire cable diagnostics commands
Command
Value
Action
show cable-diagnostics tdr
interface [gigabitethernet
gi_port | tengigabitethernet
te_port]
gi_port: (1..8/0/1..24);
te_port: (1..8/0/1..4).
Show results for the last virtual cable testing for the specific
interface (if the port number is not defined, the command is
executed for all ports).
show cable-diagnostics
cablelength interface
[gigabitethernet gi_port |
tengigabitethernet te_port]
Show the assumed cable length connected to the specific interface
(if the port number is not defined, the command is executed for all
ports).
The interface should be enabled and operate at 100Mbps
or 1000Mbps.
Maximum cable length for testing should not exceed 120m.
Example execution of commands:
 Test port 24:
console# test cable-diagnostics tdr interface gigabitethernet 1/0/24
console#test cable-diagnostics tdr interface GigabitEthernet0/24
..
Port Pair Result Length [m] Date
--------- ---- ------------------- ---------- --------------------------
gi1/0/24 1-2 Open 10 14-Mar-2014 13:41:43
3-6 Open 10
4-5 Open 10
7-8 Open 10
Given below are the possible testing results for pairs:
