18 MES3000 Ethernet switch series
Data transfer rate
electric interfaces 10/100/1000 Mbps
optical interfaces 1/10 Gbps
Table of MAC addresses
16,000 records (some MAC addresses are reserved by the system)
TCAM routing volume
for routing: 3272x24В
for the processing of traffic tasks: 2048x24B
SQinQ rules qty
Ingress: 980
Egress: 140
ACL rules qty
1012
VLAN support
up to 4K active VLANs according to IEEE 802.1Q
Quality of Services (QoS)
Traffic priority, 8 tiers
8 output queues with different priorities for each port
Multicast
up to 1024 static multicast groups
ACL quantity
1024
General quantity of rules in ACL
up to 2048
Quantity of L3 interfaces
512
LAG
12 groups, up to 8 ports per group
MSTP instances qty
64
Jumbo frames
Max. packet size 10K
Stacking
Up to 8 devices
Compliance
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-T Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
IEEE 802.3z Fiber Gigabit Ethernet
ANSI/IEEE 802.3 Speed auto detection
IEEE 802.3x Data flow control
IEEE 802.3ad LACP link aggregation
IEEE 802.1p Priority of traffic
IEEE 802.1q VLAN virtual local networks
IEEE 802.1v
IEEE 802.3 ac
IEEE 802.1d STP spanning tree
IEEE 802.1w RSTP rapid spanning tree
IEEE 802.1s MSTP multiple spanning tree
IEEE 802.1x User authentication
Control
Local control
SNMP, CLI
Remote control
TELNET, SSH, WEB
Physical specifications and ambient conditions
Power supply
AC: 220V+-20%, 50Hz
DC: -36 .. - 72V
Power options:
- Single AC or DC power supply
- Two AC or DC power supplies with hot swapping
Power consumption
50W max.
Weight
3.6kg max.
Dimensions
430x44x265mm
Operating temperature range
from -10 to +45
о
С
Storage temperature range
from -40 to +70
о
С
Operation relative humidity (non-
condensing)
up to 80%
Storage relative humidity (non-
from 10% to 95%
